Model RO

Features & Benefits

Locking Type

The Model RO incorporates a Lock Open Only feature allowing the clamp to be Locked Open,
lifted onto a hot plate and the lock released without the operator coming in close contact with the hot plate.

*Call 866-392-2829 for availability and pricing

Download Model_RO_Manual

Technical Specs

Freight Policy

ORDERS OVER $899 will have free standard shipping to COMMERCIAL ADDRESS.
NOTICE!! FREIGHT TO RESIDENTIAL ADDRESSES:
Residential addresses include private homes (including businesses operating within a private residence), apartments, camps, churches, schools, day cares,
farms, public storage facilities, and other locations not generally recognized as commercial locations and shall apply to the entire premises.

Alternatives:
1. The trucking company can hold your order at the nearest terminal.
There may be additional storage fees acumulated if orders are not picked up within 2-3 days.
2. There is a $60 surcharge for appointments/call ahead deliveries.

Part Number	Rated Capacity Tons	Plate Thickness A	B	C	D	E	F	G	Weight
RO-35.00-A*	35	1/4 - 4 1/4"	8 3/8	23 5/8	5 1/16	5	21 3/8	8	470
RO-35.00-B*	35	4 - 8"	8 3/8	23 5/8	5 1/16	5	25 1/8	8	515
RO-50.00-A*	50	1/2 - 6 1/2"	13	44 3/4	9	5	36	13 1/2	1370
RO-50.00-B*	50	6 - 12"	13	44 3/4	9	5	41 1/2	13 1/2	1500
RO-75.00-A*	75	1/2 - 6 1/2"	16 1/2	46 3/4	14 1/4	11	42 1/2	12 1/2	2700
RO-75.00-B*		3 - 9"	16 1/2	46 3/4	14 1/4	11	45	12 1/2	2775
RO-75.00-C*		6 - 12"	16 1/2	46 3/4	14 1/4	11	48	12 1/2	2850
RO-75.00-D*		8 - 14"	16 1/2	46 3/4	14 1/4	11	50	12 1/2	2900
No operator should engage or attempt to engage in the use of any RENFROE® product until the applicable manual has been read and fully understood. Failure to review and utilize recommended applications, operating and maintenance instructions could result in serious injury to the operator and others. SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE. OTHER CAPACITIES AVAILABLE UPON REQUEST. *Call 866-392-2829 for availability and pricing
