Features & Benefits
Locking Type
Model LPA is an ergonomic vertical lifting
clamp capable of turning a single plate
or member from horizontal to vertical to
horizontal through a 180° arc. It incorporates
an auxiliary push button lock. Permits side
loading of lifting shackle to 90° by de-rating
of clamp’s capacity. Refer to Figure 1 for
de-rated capacities. The “Lock Open – Lock
Closed” feature facilitates attaching and
removing the clamp from the plate.
The Model LPA incorporates a pivoting
shackle that permits side loading of the
lifting shackle at 100% of rated capacity
from vertical to 30°, 75% of rated capacity
between 30° and 45°, and 50% of rated
capacity between 45° and 90°. See Figure 1.
- Ergonomic Lifting Clamp
- Single plate turning from horizontal to vertical to horizontal through a 180 degree arc
- Incorporates auxiliary push button lock
- Permits side loading of lifting shackle to 90 degrees by de-rating clamps capacity
- Lock Open - Lock Closed Feature
- Allows easy attaching & removing of the clamp
Technical Specs
Purchase Below
| Part Number | Description | Brand | Weight | Price | Quantity | Total | Total weight | |
| LPA-00.50-A | 1/2 ton - Plate Thickness 0-5/8" Model LPA Lifting Clamp | JC Renfroe | 4 | $856.00 | $856.00 | 4 | ||
| LPA-01.00-A | 1 ton - Plate Thickness 0-3/4" Model LPA Lifting Clamp | JC Renfroe | 5 | $1,033.00 | $1,033.00 | 5 | ||
| LPA-02.00-A | 2 ton - Plate Thickness 0-1" Model LPA Lifting Clamp | JC Renfroe | 16 | $1,526.00 | $1,526.00 | 16 | ||
| LPA-03.00-A | 3 ton - Plate Thickness 0-1" Model LPA Lifting Clamp | JC Renfroe | 32 | $1,806.00 | $1,806.00 | 32 |
Purchase Below
1/2 ton - Plate Thickness 0-5/8" Model LPA Lifting Clamp
Code:
LPA-00.50-A
Brand:
JC Renfroe
Weight:
4
lbs
Price:
$856.00
Total:
$856.00
Total weight:
4
lbs
1 ton - Plate Thickness 0-3/4" Model LPA Lifting Clamp
Code:
LPA-01.00-A
Brand:
JC Renfroe
Weight:
5
lbs
Price:
$1,033.00
Total:
$1,033.00
Total weight:
5
lbs
2 ton - Plate Thickness 0-1" Model LPA Lifting Clamp
Code:
LPA-02.00-A
Brand:
JC Renfroe
Weight:
16
lbs
Price:
$1,526.00
Total:
$1,526.00
Total weight:
16
lbs
3 ton - Plate Thickness 0-1" Model LPA Lifting Clamp
Code:
LPA-03.00-A
Brand:
JC Renfroe
Weight:
32
lbs
Price:
$1,806.00
Total:
$1,806.00
Total weight:
32
lbs
