DynamicLift™ Magnet

Features & Benefits

These lightweight and powerful Rare Earth permanent lift magnets can be used on flat or round surfaces and contain an internal release
On/Off device that does not contact or damage the surface of the part being lifted. DynamicLifts also offer excellent holding on thin gauge
ferrous metals to comparable Rare Earth lift magnets.

  • On/Off actuated Rare Earth design
  • Lifts flat or round loads horizontally and flat loads vertically
  • Heat resistant up to 180F (82C)
  • Top rotating and Locking On/Off handle
  • 3:1 Design Factor
  • ASME B30.20 BHT-1 Design Category B Service Class 3
show image
select image
select image

Technical Specs +   Show table

Working Load Limit (wLL) in lbs & *Maximum Sheet Length For Single Magnet Use

Part Number
Vertical Flat Part / Sheet Lifting Applications
Horizontal Round Part Lifting Applications
WLL 1/4"(6 Lg)
WLL 3/8"(8 Lg)
WLL 1/2"(8 Lg)
WLL (lbs)Minimum Thickness (in.)WLL(lbs)MinimumDiameter (in.)Minimum WallThickness (in.)Max. WLL(kbs) at Min. Dia. & Thickness
DL0150
150
150
150
37.51.00752.000.12565
DL0334
275
320
334
83.5
1.00
167
4.00
0.125
100
NOTE: the Working Load Limit (WLL) values for the DynamicLift Magnets are stated at 33% of the actual value. We recommend when lifting sheets over 8 feet in length, use 2 or more lifts on a spreader bar to prevent sheet flexing, sagging or peel-off. Thin material is susceptible to magnetic bleed through, resulting in two sheets being lifted at once. Consult the factory before specifying these magnets for use on round materials. Round Item WLL Values are based on ideal conditions. Length, wall thickness, diameter and surface can all affect the magnets performance. *Maximum sheet lengths are selected due to the sag characteristics of the specified sheet. The item to be lifted must cover the entire length and width of the magnetic poles to properly engage and release.
Rare Earth DynamicLift® Magnets
Part Number
Overall
Magnet
Bail
Weight (lbs)
WLL (lbs)
Ht. (in.)
Ln. (in.)
Ht. (in.)
Wd. (in.)
Ln. (in.)
Th. (in.)
Ht. (in.)
Wd. (in.)
DL0150
150
9.00
4.25
2.75
2.50
3.00
0.25
2.25
3.00
6.1
DL0334
334
9.75
5.75
3.00
4.00
4.25
0.25
2.25
4.00
13.3

Purchase Below

Part Number Description Brand Weight Price Quantity Total Total weight
DL0150 Rare Earth DynamicLift™ Magnets - WLL 150 lbs. Industrial Magnetics 6 $646.35 $646.35 6
DL0334 Rare Earth DynamicLift™ Magnets - WLL 334 lbs. Industrial Magnetics 13 $1,250.00 $1,250.00 13

Purchase Below

Rare Earth DynamicLift™ Magnets - WLL 150 lbs.
Code: DL0150
Brand: Industrial Magnetics
Weight: 6 lbs
Price: $646.35
Total: $646.35
Total weight: 6 lbs
Rare Earth DynamicLift™ Magnets - WLL 334 lbs.
Code: DL0334
Brand: Industrial Magnetics
Weight: 13 lbs
Price: $1,250.00
Total: $1,250.00
Total weight: 13 lbs
