Features & Benefits
- Non-welded Construction.
- No Minimum Load
- Camming Stationary Jaw
- Camming Stationary Jaw Automatically Returns to Preload Position
- Self Locking Jaw Closed Mechanism
- Self Locking Jaw Open Mechanism
- 0 - 180 Degree Turning Permissible
- Clamp can be mounted to the work piece without the need for the operator to put hands in the fall path of the work piece
- Designed with a 5 -1 Design Factor Criteria
- ASME B30.20 Operation Compliant
- ASME B30.BTH -1 Design Compliant
- Working Load Limit (WLL) Clearly and Legibly Marked on the Clamp
- Serial Number Clearly and Legibly Marked on the Clamp
- Materials of Manufacture Remain Stable Under Load
- Clamps Can Be Used to Lift Materials with a Surface Hardness of up to 400 Brinell.
- Clamps must be used in accordance with the Instructions in the Operator Manual.
- Operating temperature -40 to 170 Fahrenheit.
Technical Specs
Purchase Below
| Part Number | Description | Brand | Weight | Price | Quantity | Total | Total weight | |
| 21336 | Jaw 0 - 0.5 Straight Plate Clamp WLL 0 - 1,100 lbs. | M&W | 6 | $746.39 | $746.39 | 6 | ||
| 21716 | Jaw 0.5 - 1.0 Straight Plate Clamp WLL 0 - 1,100 lbs. | M&W | 6 | $774.03 | $774.03 | 6 | ||
| 21717 | Jaw 1.0 - 1.5 Straight Plate Clamp WLL 0 - 1,100 lbs. | M&W | 7 | $801.68 | $801.68 | 7 | ||
| 21851 | Jaw 0 - 0.75 Straight Plate Clamp WLL 0 - 2,200 lbs. | M&W | 11 | $1,009.00 | $1,009.00 | 11 | ||
| 21852 | Jaw 0.75 - 1.5 Straight Plate Clamp WLL 0 - 2,200 lbs. | M&W | 12 | $1,036.65 | $1,036.65 | 12 | ||
| 21853 | Jaw 1.5 - 2.25 Straight Plate Clamp WLL 0 - 2,200 lbs. | M&W | 13 | $1,064.29 | $1,064.29 | 13 | ||
| 21912 | Jaw 0 - 1.0 Straight Plate Clamp WLL 0 - 4,400 lbs. | M&W | 20 | $1,071.76 | $1,071.76 | 20 | ||
| 21913 | Jaw 1.0 - 2.0 Straight Plate Clamp WLL 0 - 4,400 lbs. | M&W | 22 | $1,145.29 | $1,145.29 | 22 | ||
| 21914 | Jaw 2.0 - 3.0 Straight Plate Clamp WLL 0 - 4,400 lbs. | M&W | 24 | $1,219.10 | $1,219.10 | 24 | ||
| 22685 | Jaw 0 - 1.5 Straight Plate Clamp WLL 0 - 11,000 lbs. | M&W | 66 | $3,040.84 | $3,040.84 | 66 | ||
| 22686 | Jaw 1.5 - 3.0 Straight Plate Clamp WLL 0 - 11,000 lbs. | M&W | 70 | $3,093.49 | $3,093.49 | 70 | ||
| 22687 | Jaw 3.0 - 4.5 Straight Plate Clamp WLL 0 - 11,000 lbs. | M&W | 74 | $3,146.15 | $3,146.15 | 74 |
